Coaxial Cables

Frequency range (MHz) 850~900/1800~2100mhz VSWR ≤1.5 Gain(dBi) 3.5 dBi Maximum input protection(W) 50 Lighting protection DC ground Impedance (Ω) 50 Mechanical Properties Weight(Kg) 1.1 kg Random Color Operating temperature (℃) -40～ +65 Environmental Friendly ROHS compliant Connect type SMA male or customized 1 Black 850~900/1800~2100mhz Front to Back Ratio ≥ 15 dB POLARIZATION Vertical Radiation direction Omni direc

Items MaterialItems Diameter(mm) Center conductor silver plated copper cover 0.94 Dielectric Solid PTFE 2.95 1 out shield silver plated copper wire braiding 3.60 2 out shield silver plated copper wire braiding 4.191 Jacket FEP (BROWN) 4.95 __________________________________________________________________________

Center Conductor Bare Copper wire 7/ 0.15±0.008 Insulation Solid PE 1.50±0.05 Shield Bare Copper Wire Braiding 16*4/0.08(87%) Jacket PVC(Black) 2.8±0.15

Cutoff Frequency 3 GHz Characteristics Impedance 50±2.5Ω Capacitance 95.50pF/m Min. Bending Radius mm Nominal Weight Kg/100m Temp Range -55° to +200°C

Center Conductor Silver Plated Copper cover steel wire 7/ 0.102 Insulation Solid PTFE 1.6 Shield Tin Plated Copper Wire Braiding 16/5/0.1(18-19) Tin Immersion 3.52 Jacket FEP(Brown) 2.54

Center Conductor Bare Copper 0.0900 inch 2.29 mm Dielectric Foamed Polyethylene 0.285 inch 7.24 mm Outer Shield Copper Braid 0.314 inch 7.98 mm Jacket Black PVC 0.405 inch 10.29 mm

Center Conductor Bare Copper wire 7/0.752 Insulation Solid PE 7.24 Shield Double Copper wire barding 93%+90% Jacket PVC 10.8

Center Conductor Bare Copper wire 2.69 Insulation Solid PE 9.40 Shield Double Copper wire barding 90%+90% Jacket PVC 13.84

Item Material Siameter(MM) Conductor SCC 0.90mm Insulation Solid Polyethylene 2.95mm Shielding Two SCC 95%C Jacket Black PVC 5.3mm

Center Conductor Silver Coverd Copper 7/0.18 Insulation PTFE 1.52 Wire Braide Silver Coverd Copper 80*0.10 Jacket FEP 2.54

Center Conductor Silver Coverd Copper 7/0.18 Insulation PTFE 1.52 Wire Braide Silver Coverd Copper 80*0.10 Jacket FEP 2.54

Type of cable Coaxial Cable 2 No of Cores 1 3 Conductor :----- A Meterial Tinned Copper B No of strands 1 C Diameter of Each Strands MM 0.71 ± 0.015 MM D Nominal Cross Section Area Sqmm 0.395 4 Insulation :----- A Meterial Polythelin B Type Polythelin C Insulation Thickness MM 1.00 ± 0.05 D Core Diameter MM 2.85 ± 0.2 5 SHIELDED :------------------- A Braiding Copper Alloy Copper B Brading Coverege % 70 ± 5 %

Type of cable Coaxial Cable 2 No of Cores 1 3 Conductor :----- A Meterial Tinned Copper B No of strands 1 C Diameter of Each Strands MM 0.71 ± 0.015 MM D Nominal Cross Section Area Sqmm 0.395 4 Insulation :----- A Meterial Polythelin B Type Polythelin C Insulation Thickness MM 1.00 ± 0.05 D Core Diameter MM 2.85 ± 0.2 5 SHIELDED :------------------- A Braiding Copper Alloy Copper B Brading Coverege % 70 ± 5 %

Center Conductor Silver Plated Copper cover steel wire 7/ 0.102 Insulation Solid PTFE 1.6 Shield Tin Plated Copper Wire Braiding 16/5/0.1(18-19) Tin Immersion 3.52 Jacket FEP(Brown) 2.54
